Generator

STYLES

Tie-rod box

Tie-rod box

Rated AC Voltage(v)

120/110/230V

120/110/230V

Rated Frequency(Hz)

50/60

50/60

Rated AC Output Power(kW)

3.0

3.2

Max AC Output Power(kW)

3.3

3.5

DC Output

12V/8.3A

12V/8.3A

Fuel Tank Capacity(L)

6.7

6.7

Noice Level(7m@25%)(dB)

63

63

Power Factor(cos)

1.0

1.0

Engine

Model

164F/P-1

165F/P

Displacement(cc)

145

160

Ignition Mode

TDI

TDI

Starting Mode

Recoil start/ Electric start

Recoil start/ Electric start

Oil Capacity(mL)

430

430

Package

Product Dimensions(mm)

540×310×505

540×310×505

Package Dimensions(mm)

560×330×520

560×330×520

Net Weight/Gross Weight(kgs)

23/28

23/28
