STYLES

Tie-rod box

Rated AC Voltage(v)

120/110/230V

Rated Frequency(Hz)

50/60

Rated AC Output Power(kW)

5.0

Max AC Output Power(kW)

5.5

DC Output

12V/8.3A

Fuel Tank Capacity(L)

15

Noice Level(7m@25%)(dB)

64

Power Factor(cos)

1.0

Model

180F/P-2

Displacement(cc)

312

Ignition Mode

TDI

Starting Mode

Recoil start/ Electric start

Oil Capacity(mL)

800

Product Dimensions(mm)

610×470×535

Package Dimensions(mm)

650×510×605

Net Weight/Gross Weight(kgs)

52/57
