Generator

Frequency (Hz)

50

60

Rated voltage (V)

220、230、240、380、400、415

(rpm)

3000

3600

Rated output(kva)

10

Max output (kva)

10.5

Power factor

1

Number of phase

Single phase/Three-phase

Excitation way

External rotor multipole permanent magnet type

Insulation class

F

Type of generator

Medium frequency/rare earth permanent magnet variable frequency multistage motor

Waveform distortion rate

3%

Application scope of load features

Inductive, capacitive, nonlinear, resistive load

Frequency conversion type

IGBT digital frequency conversion

Way to work

12 hours of continuous operation

Engine

Engine model

2V80

Engine type

V-shaped cylinder,4-stroke,Water-cooled,Direct injection

Bore*stroke(mm)

80*79

Displacement(L)

0.794

Compression ratio

23：1

(KW/rpm)

12.5/3000

14.5/3600

Lube oil capacity

3.6L

Fuel type

0＃(summer)-10＃(wenter)，-35＃(Very cold)diesel

Type of lubricating oil

SAE10W30(CD magnitude)

Generating set

Fuel consumption 100% Load (g/kw.h)

≤250

Fuel tank capacity (L)

28

Continuous running time (hr)

10

9.5

The noise level (7m) db (A)

80

82

Starting system

Electric start

Packing size (L*W*H) mm

1380*780*1085

Net weight (kg)

240
