Combustion System

Direct Injection

Bore*Stroke (mm)

88*75

Displacement

0.912

Compression Ratio

20:01

Rated Power (kW/rpm)

13.8/3000; 14.8/3600

Rated Speed (rpm)

3000/3600

Starting System

Electric start

Lube Oil Capacity (L)

3

Fuel Consumption (g/kW.h)

250 @ 3000rpm

260 @ 3600rpm

Fuel

0# (summer), -10# (winter)

Lube Oil

SAE10W30 (CD grade above)

Rotation Direction

Clockwise (view from flywheel)

Shaft Height (mm)

185

Packing Size (mm)

640*640*845

Net Weight

68

Quantity for 20GP

54

Quantity for 40HQ

162

Unit Price (FOB SHANGHAI)

** Price quoted without fuel tank. For fuel tank, price should add 30USD.

Packing
