Weight

kg

1320

Bucket capacity

m3

0.025

Working device mode

backhoe

engine model

淮 2TNV70

Rated power/speed

kw/rmp

7.8

System pressure

Mpa

16

Swing speed

rmp

11

Maximum climbing angle

o

35

Travel speed (high/low speed)

Km/h

1.5

Hydraulic tank volume

L

22

Fuel tank volume

L

18

Dimensions

Unit

Specificatin

Tyre gauge

mm

800

Track length

mm

1220

Platform ground clearance

mm

375

Width of chassis

mm

980

Width of track

mm

180

Track material

Ship track

Machine height

mm

1950 （retract）

Operating range

Unit

Specificatin

Max. digging radius

mm

2900

Max. digging depth

mm

1650

Max. digging height

mm

2350

Max. dumping height

mm

1650

Max. vertical depth

mm

1650

Min. gyration radius

mm

1550

Max. lifting height of dozer blade

mm

150

Max. lifting depth of dozer blade

mm

160
