Excavation height

2490mm

Standard Bucket Capacity

0.02m³

Rated power

14KW

Digging depth

1400mm

Product model

KV13X

Unload height

1750mm

Chassis width

940mm

Total Weight

1300KG

Radius of gyration

1190mm

*All dimensions are measured by hand, there are certain errors

Weight

kg

1150

Bucket capacity

m3

0.028

Working device mode

backhoe

Power

kw

12.3

Dimensions

Unit

Specificatin

Tyre gauge

mm

770

Track length

mm

1090

Platform ground clearance

mm

380

Rear-end swing radius

mm

733

Width of chassis

mm

946

Width of track

mm

180

Hight of track

mm

320

Over length

mm

2700

Machine height

mm

1330

Operating range

Unit

Specificatin

Max. digging radius

mm

2500

Max. digging depth

mm

1800

Max. digging height

mm

2750

Max. dumping height

mm

1950

Max. vertical depth

mm

1530

Min. gyration radius

mm

1250

Max. lifting height of dozer blade

mm

325

Max. lifting depth of dozer blade

mm

175
