Gen set

Frequency

50Hz

Rated voltage

400V

The prime power

18KW

The standby power

20KW

Rated ampere

26.0A

Max. ampere

29.0A

Phase No.

Three phase

Noise

≤75dB/7m

Size

1800*900*1300mm /
2500*1500*1850 (with trailer)

Net weight

700kg / 750kg (with trailer)

Welder

Phase

3 phase 400V 50Hz

Rated input ampere

26A

Rated input power

17 KVA

Rated welding A/V

400A / 36V

Welding ampere

400A 60%DE

310A 100%DE

No load voltage

67±5V

Ampere set range

20-400A

Efficiency

≥85%

Power factor

>0.95

Insulation grade

F

Cooling system

Water cooled

Protection grade

IP21S

Alternator

Excitation mode

Brushless self excitation

The prime power

20KW

Rated frequency

50Hz

RPM

1500r/min

Rated voltage

400V

Phase & connection

3 phase , star connection

Insulation grade

H

Safeguard grade

IP23

Engine

Engine

WP2.3D25E200

Power/h

25KW

RPM

1500 r/min

Startup

DC12V electric

Engine type

Inline ,direct injection

Intake mode

Natural intake

Stroke

4

Cylinder No.

4

Bore x stroke

80x90mm

Governing control

Electron governor

Displacement

2.289L

Fuel consumption

≤200g/kWh

Oil consumption

≤1.5g/kWh
