Gen set

Frequency

50Hz

Rated voltage

400V

The prime power

30KW

The standby power

33KW

Rated ampere

26.0A

Max. ampere

29.0A

Phase No.

Three phase

Noise

≤75dB/7m

Fuel capacity

80L

Size

1800x900x1300mm

N.G

700kg

Welder

Rated input ampere

38A

Rated welding A/V

500A / 40V

Welding ampere

500A 60%DE

400A 100%DE

No load volt (V)

75

Rated load volt (V) 40%

60

Ampere set range

20-500A

Power factor (COSφ)

0.8

Engine

Engine

Weichai WP2.3D33E200

RPM

1500r/min

Displacement (L)

2.3

Startup mode

DC12V electric start

Type

Inline, direct injection

Intake mode

Turbo charged

Stroke

4

Cylinder No.

4

Bore /stroke

100/115mm

Fuel consumption

≤200g/KW.h

Alternator

WHI184H

Brushless self excitation

Phase

3 phase

The prime power

30KW

RPM

1500r/min

Frequency

50HZ

Voltage

400V

Power factor

0.8

Phase& connection

3 phase star connection

Excitation

AVR

Insulation grade

H
